| X-3100 Technical Parameter | |||||||
| Model | X-3100 | ||||||
| Item | wired Laser Barcode Scanner | ||||||
| Physical Parameter | |||||||
| Material | ABS+PVC+PC | ||||||
| Power Supply | DC 5V ±5% | ||||||
| Operating Current | 50mA（Standby）；30mA（Operating）；100mA（Max） | ||||||
| consumption | 0.5W | ||||||
| Weight | 131±5g（Excluding wire） | ||||||
| Size | L * W * H：171.0 * 80.6 * 112.3（unit:mm） | ||||||
| Color | Black; Grey white | ||||||
| Button life | ＞100000 | ||||||
| Performance Parameter | |||||||
| Interface | USB、PS/2；（RS232 Customizable） | ||||||
| System supported | Linux，Android，Windows XP、7、8、10，MAC | ||||||
| Language supported | English; French; Dutch; Spanish (International); Italian (Italy 142); German; Argentina; Brazil; Denmark; Norway; Finland; Portugal; Czech Republic; Poland; Switzerland; Japanese; Russian; Arabic; Türkiye Q; Türkiye F; Netherlands; Slovakia; (Support for virtual keyboards) | ||||||
| light source | Visible laser 650nm | ||||||
| Resolution | ≥4mil | ||||||
| Error Rate | 1/5000000 | ||||||
| Decoding speed | 300/sec | ||||||
| Reading mode | laser | ||||||
| Triggle Mode | Manual mode; Continuous scanning mode | ||||||
| Reading distance | 10mm-600mm | ||||||
| Feedback method | Buzzer+indicator light (LED) | ||||||
| Print contrast | ≥30% | ||||||
| Decoding Capability | ●Code25-Interleaved ●Code25-Standard ●Code25-Matri ●Code39-Regular ●Code39-FullASCII ●Code32 ●Code93-Regular ●Code93-FullASCII ●Code128 ●EAN/GSL/UCC-128Auto ●Codabar ●MSI ●EAN/JAN-13 ●UPC-A ●JAN-8 ●Code11 ●UPCE0 | ||||||
| Scanning Angle | Angle 30 °, elevation angle 65 °, inclination angle 65 ° | ||||||
| Scanning Depth | Code39 4.17mil（15 byte）：1cm - 9cm Code39 7.50mil（15 byte）：3cm - 18cm Code128 4.17mil（15 byte）：1cm - 9cm | ||||||
| Environment Parameter | |||||||
| IP level | IP52 | ||||||
| Operating Temp. | 0 to 50℃ / 32 to 122℉ | ||||||
| Storage Temp. | 0 to 50℃ / 32 to 122℉ | ||||||
| Operating Humidity | 20% to 85%（No condensation） | ||||||
| Storage Humidity | 20% to 85%（No condensation） | ||||||
| Electrostatic protection | 15KV air discharge | ||||||
| Earthquake resistance | Free fall 1.5m (concrete floor) | ||||||
| ambient lighting | 0~10000LUX | ||||||
